The de Havilland DH.87 Hornet Moth is a single-engined cabin biplane designed by the de Havilland Aircraft Company in 1934 as a potential replacement for its highly successful de Havilland Tiger Moth trainer. Although its side-by-side two-seat cabin made it closer in configuration to the modern aircraft that military trainee pilots would later fly, there was no interest from the RAF and the aircraft was put into production for private buyers.

Design and development

The prototype first flew at Hatfield on 9 May 1934 and, with two other pre-production aircraft, embarked on an extensive test program that resulted in the first production aircraft (designated DH.87A) completed in August 1935 having wings of greater outboard taper. These were found to cause problems, especially when landing in three-point attitude: there was a tendency for the tips to stall, causing embarrassment to the pilot and often damage to the aeroplane. From early 1936, de Havilland offered owners of the DH.87A replacement wings of the new squarer shape at a reduced price in exchange for the original wings. Designated DH.87B, new aircraft from about manufacture Number 68 were built with the new square wings. This wing reduced the overall span by 8 inches (20 cm). The alterations slightly increased overall weight at some penalty to performance.

A total of 164 aircraft were produced, of which 84 were placed on the British Register. Many were impressed for military service during World War II, mostly being used by the RAF as liaison aircraft.

Small numbers survived the war and with time became highly prized by vintage aircraft enthusiasts. A small number are still flying, over eighty years after production ceased.

Variants

  • DH.87 Hornet Moth : prototypes
  • DH.87A Hornet Moth : production model
  • DH.87B Hornet Moth : production model with wing modification

Operators

Civil charter operators and pilots 1935–2009

 United Kingdom
 Australia
 Austria
 Belgium
 Canada
 Denmark
 France
 India
 South Africa
 Spain
  Switzerland
 Turkey - TC-101

Military operators

 France
  • L'Armée de l'Air
 Portugal
  • Portuguese Air Force
 South Africa
  • South African Air Force
 United Kingdom
  • Royal Air Force (1940–1945)
    • No. 24 Squadron RAF
    • No. 49 Squadron RAF
    • No. 116 Squadron RAF
    • No. 510 Squadron RAF
    • No. 526 Squadron RAF
    • No. 527 Squadron RAF
    • No. 528 Squadron RAF
    • No. 529 Squadron RAF
  • Royal Navy Fleet Air Arm
    • One aircraft impressed and four from Canada

Specifications (DH.87B)

Data from Jane's All the World's Aircraft 1938, De Havilland Aircraft since 1909

General characteristics

  • Crew: 1
  • Capacity: 1 passenger / trainee
  • Length: 24 ft 11.5 in (7.607 m)
  • Wingspan: 31 ft 11 in (9.73 m)
  • Height: 6 ft 7 in (2.01 m)
  • Wing area: 244.5 sq ft (22.71 m2)
  • Airfoil: RAF 15
  • Empty weight: 1,241 lb (563 kg)
  • Gross weight: 1,950 lb (885 kg)
  • Fuel capacity: 35 imp gal (42 US gal; 159 L) fuel in fuselage tank; 2 imp gal (2 US gal; 9 L) oil in an air-cooled tank
  • Powerplant: 1 × de Havilland Gipsy Major I 4-cylinder air-cooled inverted in-line piston engine, 130 hp (97 kW)
  • Propellers: 2-bladed fixed-pitch propeller

Performance

  • Maximum speed: 124 mph (200 km/h, 108 kn) at sea level
  • Cruise speed: 105 mph (169 km/h, 91 kn) at 1,000 ft (305 m)
  • Stall speed: 40 mph (64 km/h, 35 kn)
  • Range: 620 mi (1,000 km, 540 nmi)
  • Service ceiling: 14,800 ft (4,500 m)
  • Rate of climb: 690 ft/min (3.5 m/s)
  • Time to altitude: 5,000 ft (1,524 m) in 8 minutes 45 seconds
  • Wing loading: 7.97 lb/sq ft (38.9 kg/m2)
  • Power/mass: 0.067 hp/lb (0.110 kW/kg)

References

Notes

Bibliography

  • Comas, Matthieu (September–October 2020). "So British!: 1939–1940, les avions britanniques dans l'Armée de l'Air" [So British!: British Aircraft in the French Air Force 1939–1940]. Avions (in French). No. 236. pp. 38–61. ISSN 1243-8650.
  • Jackson, A.J. De Havilland Aircraft since 1909. London: Putnam, Third edition, 1987. ISBN 0-85177-802-X.
  • Sturtivant, Ray; Burrow, Mick (1995). Fleet Air Arm Aircraft 1939 to 1945. Tunbridge Wells, UK: Air-Britain (Historians) Ltd. ISBN 0-85130-232-7.
  • Follett, K. "Hornet flight", (translated in Italian "Il volo del calabrone", Mondadori Editore S.p.A., Milano, 2003 ISBN 88-04-54428-7) It's a fictitious novel, first printed in 2002, in which a hornet moth plays a key role in the story.

External links

  • The de Havilland Moth Club

De Havilland DH87B Moth Untitled Aviation Photo 1220248

De Havilland DH87B Moth Untitled Aviation Photo 2145495

De Havilland Moth RoyaltyFree Images, Stock Photos & Pictures

De Havilland DH87B Moth Untitled Aviation Photo 2318463

De havilland moth hires stock photography and images Alamy
